4. Mechanical Instructions
Index of this chapter:
4.1
Cable Dressing
4.2 Service Positions
4.3 Assembly/Panel Removal 32" Dali
4.4 Assembly/Panel Removal 32" Smart Choice
4.5 Assembly/Panel Removal 42"
4.6 Returning a defect 32" or 42" Dali styling, LCD panel
4.7 Assembly/Panel Removal 47"
4.8 Set Re-assembly.
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing
Figure 4-1 Cable dressing (32" Smart Choice styling)
18854_100_110816.eps
110816
To Next Page
