3.3 Product overview
3.3.1 Front and rear sides
a ON/OFF switch / HOLD (keypad lock)
b Micro USB port for computer connection
c Status LED:
Red–device is recording
Green–device is playing back
Yellow–data is being transferred to/from the computer
d Display
e Operating panel with keys
f Speaker
g Operating panel with keys
h Microphone
i Headphone socket
(stereo jack, 3.5 mm)
j Battery compartment
