Philips VR630 - Page 49

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR630/39 VR630/02 VR630/16 VR330/07 VR530/39 VR630/07 VR330/02 VR330/39
D152 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 or 111111
D153 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 11111111
D154 9965 000 12178 ZENER DIODE DZ-11BSAT265 11111
D155 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 111111
D156 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 11111
D301 4822 130 30621 SWITCHING DIODE 1N4148M or 11111111
D370 4822 130 30621 SWITCHING DIODE 1N4148M or 1 1 1
D501 4822 130 30621 SWITCHING DIODE 1N4148M or 11111111
D502 9965 000 05250 LED SIR-563ST3F P or 11111111
D552 4822 130 10094 ZENER DIODE MTZJT-777.5A 11111
D553 4822 130 30621 SWITCHING DIODE 1N4148M or 11111111
D701 4822 130 81729 ZENER DIODE MTZJT-7733D 11111111
F001
h
9965 000 12179 FUSE 21301.6M 11111111
FH001 4822 256 10461 FUSE HOLDER MSF-015 11111111
FH002 4822 256 10461 FUSE HOLDER MSF-015 11111111
FP562 9965 000 09307 LED DISPLAY LFU-4421-2001A 11111111
IC’s
IC001
h
4822 130 11655 PHOTOCOUPLER LTV-817B-F or 11111111
IC151 5322 209 17147 IC:SWITCHING TC4052BF(EL) or 1
IC301 9965 000 12180 IC:Y/C/A LA71750AM-MTB 11111111
IC370 9965 000 12255 IC:SECAM LA70100M-TRM 1 1 1
IC451 9965 000 12181 IC:HIFI LA72646M-A-MPB 11111
IC501 9965 000 12556 MICROCONTROLLER 16BIT M37762MFA-1B9GP 1 1 1 1111
IC501 9965 000 12557 MICROCONTROLLER 16BIT M37762MCA-1B5GP 1
IC503 9965 000 06554 IC:MEMORY BR24C02F-W or 11111111
IC561 9965 000 12183 IC:LED DRIVER PT6958-FN-TP 11111111
IC771 9965 000 12184 IC:COMPARATOR KIA339F EL or 11111111
J902 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 or 11111111
JW001 9965 000 12892 FLAT CABLE, 8P AWG26#2651/P1.25/150 1 1 1
JW001 9965 000 12411 FLAT CABLE, 11P AWG26#2651/P1.25/150 11111
JW002 9965 000 12905 FLAT CABLE, 9P AWG26#2651/P1.25/150 1
JW002 9965 000 12412 FLAT CABLE, 12P AWG26#2651/P1.25/150 11111
JW003 9965 000 12413 FLAT CABLE, 2P AWG26#2651/P1.25/120 11111111
COILS
L001 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 or 11111111
L002 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 or 11111111
L003
h
9965 000 12188 LINE FILTER 50MH LF-4Z-E503 or 11111111
L003
h
9965 000 09877 LINE FILTER 56MH TLF14CB5630R2 or 11111111
L009 9965 000 05627 CHOKE COIL 47UH-K 11111111
L010 9965 000 05627 CHOKE COIL 47UH-K 11111111
L012 4822 157 10649 INDUCTOR 100UH-K-26T 11111111
L251 9965 000 08652 INDUCTOR 5.6UH-K-26T 11111111
L301 4822 157 63316 INDUCTOR 56UH-K-26T 11111111
L370 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1
L401 9965 000 05627 CHOKE COIL 47UH-K 11111111
L402 9965 000 05627 CHOKE COIL 47UH-K 11111111
L451 4822 157 10649 INDUCTOR 100UH-K-26T 11111
L452 4822 157 10347 INDUCTOR 22UH-K-26T 11111
L501 4822 157 10649 INDUCTOR 100UH-K-26T 11111111
L561 4822 157 11509 INDUCTOR 47UH-K-26T 1 1 1
L561 4822 157 10649 INDUCTOR 100UH-K-26T 11111
L562 4822 157 11509 INDUCTOR 47UH-K-26T 1 1 1
L562 4822 157 10332 PCB JUMPER D0.6-P5.0 11111
L701 4822 157 10889 INDUCTOR 10UH-K-26T 11111111
L702 9965 000 05627 CHOKE COIL 47UH-K 11111111
L703 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1
L704 4822 157 11511 INDUCTOR 15UH-K-26T 1 1 1 1 1 1
L705 4822 157 10332 PCB JUMPER D0.6-P5.0 11111111
L851 9965 000 08629 INDUCTOR 1.8UH-K-26T 11111111
L853 4822 157 10332 PCB JUMPER D0.6-P5.0 11111111
PS503 9965 000 12189 PHOTO INTERRUPTER RPI-302C70 11111111
TRANSISTORS
Q001 9965 000 06568 FET FS1KM-18A or 11111111
Q002 4822 130 41319 TRANSISTOR 2SC1815-BL(TPE2) 11111111
Q003 4822 130 10923 TRANSISTOR KTC3199(BL) or 11111111
