ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR630/39 VR630/02 VR630/16 VR330/07 VR530/39 VR630/07 VR330/02 VR330/39
Q004 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
Q051 4822 130 42292 RES. BUILT-IN TRANSISTOR KRA104M or 11111111
Q052 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M or 11111111
Q053 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111
Q054 4822 130 42292 TRANSISTOR KTC3203(Y) or 1 1 1
Q054 9965 000 09389 TRANSISTOR 2SD1246(S) or 11111
Q056 9965 000 05388 RES. BUILT-IN TRANSISTOR BN1F4M-T 11111111
Q057 9965 000 12190 TRANSISTOR KTA1281(Y) or 11111111
Q058 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M or 11111111
Q151 4822 130 10103 TRANSISTOR KTC3199(Y) or 1
Q152 4822 130 10103 TRANSISTOR KTC3199(Y) or 1
Q153 4822 130 10103 TRANSISTOR KTC3199(Y) or 111111
Q351 4822 130 42959 TRANSISTOR KTA1266(GR) or 11111111
Q352 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
Q401 4822 130 42959 TRANSISTOR KTA1266(GR) or 11111111
Q402 4822 130 42292 TRANSISTOR KTC3203(Y) or 11111111
Q403 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M or 11111111
Q404 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
Q405 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
Q406 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
Q451 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M or 11111
Q501 4822 130 10923 TRANSISTOR KTC3199(BL) or 11111111
Q502 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M or 11111111
Q503 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 or 11111111
Q551 4822 130 10923 TRANSISTOR KTC3199(BL) or 11111111
Q552 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M or 11111111
Q771 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
Q772 4822 130 10103 TRANSISTOR KTC3199(Y) or 11111111
RESISTORS
J89 CARBON RES. 1/6W J 22K OHM 1
R001 9965 000 08653 CARBON RES. 1/2W K 5.6M OHM 11111111
R002 9965 000 08635 METAL OXIDE FILM RES. 1W J 150K OHM or 11111111
R003 CARBON RES. 1/4W J 1M OHM 11111111
R004 CARBON RES. 1/4W J 1M OHM 11111111
R005 4822 116 52243 CARBON RES. 1/4W G 1.5K OHM 11111111
R006 METAL OXIDE FILM RES. 1W J 2.2 OHM or 11111111
R007 CARBON RES. 1/6W J 22K OHM or 11111111
R008 CARBON RES. 1/6W J 100K OHM or 11111111
R009 CARBON RES. 1/6W G 5.6K OHM or 11111111
R011 CARBON RES. 1/4W J 390K OHM 11111111
R012 CARBON RES. 1/4W J 390K OHM 11111111
R013 CARBON RES. 1/6W J 470K OHM or 11111111
R014 CARBON RES. 1/6W J 100K OHM or 11111111
R015 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
R016 CARBON RES. 1/6W J 100K OHM or 11111111
R017 CHIP RES.(1608) 1/10W J 220K OHM or 11111111
R018 CHIP RES.(1608) 1/10W J 22K OHM or 11111111
R021 CHIP RES.(1608) 1/10W J 22K OHM or 11111111
R022 CHIP RES.(1608) 1/10W J 680 OHM or 11111111
R023 CHIP RES.(1608) 1/10W J 2.2K OHM or 11111111
R024 CHIP RES.(1608) 1/10W J 1K OHM or 11111111
R025 CHIP RES.(1608) 1/10W J 390 OHM or 11111111
R026 CHIP RES.(1608) 1/10W J 22K OHM or 11111111
R027 CARBON RES. 1/6W J 1K OHM or 11111111
R028 CARBON RES. 1/4W J 1M OHM 11111111
R029 CARBON RES. 1/4W J 820 OHM 1
R030 CARBON RES. 1/4W J 680 OHM 1
R035 PCB JUMPER D0.6-P5.0 11111111
R054 CHIP RES.(1608) 1/10W J 180 OHM or 11111111
R059 CARBON RES. 1/6W J 330 OHM or 1 1 1
R060 CARBON RES. 1/6W J 2.7K OHM or 11111111
R061 CHIP RES.(1608) 1/10W J 22K OHM or 11111111
R062 CARBON RES. 1/4W J 3.3K OHM 1 1 1
R062 CARBON RES. 1/4W J 10K OHM 11111
R063 CARBON RES. 1/4W J 1.2K OHM 11111111
