Philips VR730/07 - Page 21

1-10-81
1-10-82
Main CBA Parts Location Guide
Comparison Chart of
Models and Marks
MODEL MARK
VR730/02 L
VR730/07 M
VR730/16 N
VR730/39 O
VR732/02 P
VR732/16 Q
VR732/39 R
Ref No. Position Ref No. Position Ref No. Position Ref No. Position
C002 G-3 C341 C-3 C471 C-3 C851 C-2
C003 F-3 C342 C-3 C472 C-3 C852 C-2
C004 G-3 C343 C-3 C473 C-3 C853 D-2
C005 G-3 C344 C-3 C474 C-3 C854 D-2
C006 G-2 C345 D-3 C475 B-3 C855 C-1
C007 F-3 C347 C-3 C476 B-3 C856 C-1
C008 F-2 C348 D-2 C477 B-3 C858 D-2
C010 G-3 C351 C-3 C478 B-3 C859 C-1
C011 G-3 C352 D-2 C479 B-3 C862 D-2
C012 F-2 C370 D-3 C480 B-3
C014 G-2 C371 E-3 C481 C-3 CL151 A-3
C017 G-2 C372 D-3 C482 C-3 CL152 A-3
C018 G-1 C373 E-3 C483 C-3 CL253 C-4
C020 G-2 C374 D-3 C484 C-3 CL501 B-4
C021 G-1 C375 D-3 C485 C-3 CL502 E-2
C025 F-2 C376 D-3 C501 E-1 CL504 E-4
C026 F-1 C377 D-3 C502 D-1 CL505 F-1
C053 F-1 C378 D-3 C506 C-1 CL508 B-1
C056 G-1 C379 E-4 C508 C-1 CL509 B-1
C060 F-1 C381 E-3 C510 C-2 CN506 G-1
C061 F-1 C382 E-4 C511 C-1 CN701 A-2
C157 B-4 C383 E-3 C512 C-1
C158 B-3 C384 E-4 C513 C-1 D001 G-4
C251 C-3 C401 C-4 C514 C-1 D002 G-3
C252 C-3 C402 C-4 C515 C-1 D003 G-3
C253 C-3 C403 C-4 C516 C-1 D004 G-3
C254 C-3 C404 C-4 C517 E-2 D005 G-3
C302 D-3 C411 D-4 C518 E-2 D006 G-3
C303 D-3 C412 D-4 C519 D-1 D007 F-2
C304 D-3 C413 D-4 C520 D-1 D008 G-3
C305 D-3 C414 D-4 C521 D-1 D009 F-3
C307 D-3 C415 D-4 C522 D-1 D011 F-2
C308 D-3 C416 D-3 C523 E-1 D012 F-2
C309 D-3 C417 D-3 C524 E-1 D013 F-2
C310 D-3 C418 D-4 C526 E-1 D014 G-2
C311 D-3 C419 D-3 C527 D-1 D015 G-2
C312 D-3 C421 D-4 C529 D-1 D018 G-3
C313 D-3 C422 D-3 C530 D-1 D019 F-2
C314 D-3 C424 D-4 C531 C-1 D021 F-2
C315 D-3 C425 D-3 C535 D-2 D051 F-2
C316 D-3 C428 D-4 C540 E-1 D052 F-1
C317 D-3 C430 D-3 C561 E-1 D053 G-1
C318 D-3 C431 C-3 C622 D-2 D056 G-2
C319 D-3 C451 B-3 C701 A-3 D057 F-1
C320 D-3 C452 B-3 C702 A-4 D151 B-4
C321 D-3 C453 B-3 C703 A-3 D152 A-3
C322 D-3 C454 B-4 C704 A-3 D153 B-3
C323 D-2 C455 B-4 C706 A-2 D154 B-3
C324 D-3 C456 C-3 C707 A-2 D155 A-3
C325 D-3 C457 B-4 C708 A-2 D156 A-3
C326 D-3 C458 C-4 C715 A-1 D301 C-3
C327 D-3 C459 C-4 C751 B-4 D370 D-3
C328 D-3 C460 C-3 C752 A-3 D501 E-1
C329 C-3 C461 C-3 C756 A-1 D502 D-2
C330 D-3 C462 C-4 C757 A-1 D552 C-2
C332 C-3 C463 C-3 C771 E-4 D553 C-2
C333 C-3 C464 C-4 C772 F-4 D701 A-2
C334 C-3 C465 C-3 C773 E-4
C335 C-3 C466 C-3 C774 F-3 IC001 F-2
C337 C-3 C467 C-3 C775 E-3 IC301 C-3
C338 C-3 C468 C-3 C776 E-3 IC370 E-3
C339 C-3 C469 C-3 C777 E-4 IC451 C-3
C340 C-3 C470 C-3 C778 F-3 IC501 D-1
CAPACITORSCAPACITORS CAPACITORS CAPACITORS
ICS
CONNECTORS
DIODES
Ref No. Position Ref No. Position Ref No. Position Ref No. Position Ref No. Position
IC503 C-1 R006 G-3 R333 D-2 R504 C-1 R758 A-1
IC561 E-1 R007 G-3 R351 C-2 R505 C-1 R759 A-1
IC771 F-4 R008 G-3 R352 C-2 R506 C-1 R771 E-4
R009 F-2 R355 C-2 R507 C-1 R772 E-4
J902 F-3 R011 G-3 R357 D-2 R508 A-1 R773 F-4
L001 G-4 R012 G-3 R358 C-3 R509 C-1 R774 E-4
L002 F-3 R013 F-3 R360 D-3 R510 C-1 R775 E-4
L003 F-3 R014 F-3 R361 D-3 R511 C-2 R776 F-4
L009 G-1 R015 F-3 R370 E-3 R513 C-2 R777 F-3
L010 G-2 R016 F-3 R371 E-3 R514 C-2 R778 E-4
L012 F-1 R017 F-2 R372 E-3 R516 C-1 R779 E-4
L251 C-3 R018 F-2 R401 C-4 R517 C-1 R780 E-4
L301 C-3 R021 F-2 R402 C-4 R518 C-2 R781 E-4
L370 E-3 R022 F-2 R403 B-4 R519 C-2 R782 E-4
L401 B-4 R023 F-2 R404 B-4 R520 E-2 R783 E-4
L402 D-3 R024 F-2 R405 D-4 R521 E-2 R784 E-4
L451 C-3 R025 F-2 R406 D-4 R522 D-2 R785 F-4
L452 C-2 R026 G-2 R407 D-4 R523 C-1 R786 F-4
L501 E-1 R027 G-2 R408 C-3 R524 C-1 R787 F-4
L561 E-1 R028 G-3 R409 C-3 R525 C-1 R851 C-2
L562 E-1 R035 G-2 R411 C-4 R526 E-1 R852 D-2
L701 A-4 R054 F-1 R412 D-4 R527 D-1 R853 C-1
L702 A-2 R060 G-1 R413 D-4 R528 A-1
L703 A-2 R061 F-1 R414 D-4 R529 D-2 SW501 B-1
L704 B-2 R062 F-1 R415 D-3 R530 C-2 SW502 B-1
L705 A-2 R063 F-1 R416 D-3 R531 C-2 SW504 E-1
L851 C-2 R064 F-1 R417 D-3 R533 E-2 SW505 F-1
L853 C-1 R065 F-1 R421 D-4 R534 F-2 SW506 C-1
R066 F-2 R422 D-4 R535 F-2 SW507 F-1
Q001 G-2 R067 F-1 R425 D-4 R536 F-2
Q002 G-2 R068 F-1 R426 D-4 R537 F-1 VR501 A-1
Q003 F-3 R070 F-1 R429 D-3 R538 E-2
Q004 F-2 R157 B-2 R430 D-3 R539 F-1 X301 D-3
Q051 F-2 R158 B-2 R431 D-3 R540 B-1 X501 C-1
Q052 F-2 R251 C-3 R451 B-3 R541 B-1 X502 C-1
Q053 F-1 R252 C-3 R452 B-3 R542 B-1
Q054 F-1 R301 D-3 R453 B-3 R543 E-1 AC001 F-4
Q056 F-1 R302 D-3 R454 B-3 R544 E-1 F001 G-4
Q057 F-1 R303 D-3 R455 B-3 R545 F-1 FP562 D-1
Q058 G-1 R304 D-3 R456 B-4 R546 G-1 JK751 B-4
Q153 B-2 R305 D-3 R457 B-3 R547 B-1 JK756 A-1
Q351 C-2 R306 C-2 R458 B-3 R551 C-2 JK757 A-1
Q352 D-3 R307 C-3 R459 C-3 R552 C-2 JK758 A-1
Q401 C-4 R308 C-3 R460 C-4 R555 C-1 PS503 C-2
Q402 B-4 R309 C-3 R461 C-3 R556 C-1 RS501 C-1
Q403 D-4 R310 B-2 R462 C-3 R557 C-1 SA001 F-4
Q404 D-4 R311 B-2 R463 C-3 R558 C-1 T001 G-2
Q405 D-4 R312 C-2 R464 C-3 R566 E-1 TU701 A-3
Q406 D-4 R313 C-2 R465 C-3 R604 C-1
Q451 C-3 R315 C-3 R466 B-3 R605 D-2 TP301 G-1
Q501 C-1 R316 C-3 R467 B-3 R608 D-2 TP501 G-1
Q502 D-1 R317 C-3 R468 B-3 R610 C-1 TP502 B-1
Q503 D-2 R318 C-3 R469 B-3 R612 B-1 TP506 A-2
Q551 C-2 R319 C-3 R470 B-3 R614 B-1 TP507 G-1
Q552 C-2 R320 C-3 R471 B-3 R615 B-1 TP508 C-1
Q771 F-3 R321 D-3 R472 B-3 R701 A-2 TP751 B-2
Q772 F-3 R322 D-3 R473 B-3 R702 A-1
R323 D-2 R474 C-3 R703 A-1
R001 F-3 R324 C-3 R479 B-3 R706 A-1
R002 G-3 R328 D-3 R480 B-3 R751 B-4
R003 G-3 R330 D-3 R501 C-1 R752 A-3
R004 G-3 R331 D-3 R502 B-1 R756 A-1
R005 G-3 R332 D-3 R503 C-1 R757 A-1
ICS RESISTORSRESISTORSRESISTORSRESISTORS
COILS
TRANSISTORS
RESISTORS
SWITCHES
VARIABLE RESISTORS
CRYSTAL OSCILLATORS
MISCELLANEOUS
TEST POINTS
