ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR732/02 VR732/39 VR730/07 VR730/39 VR732/16 VR730/02 VR730/16
R101 CARBON RES. 1/4W J 1K OHM 1 1 1 1 1 1 1
R103 CARBON RES. 1/4W J 1K OHM 1 1 1 1 1 1 1
R104 CARBON RES. 1/6W J 4.7K OHM 1 1 1 1 1 1 1
R106 CARBON RES. 1/6W J 4.7K OHM 1 1 1 1 1 1 1
R107 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1 1
R108 CARBON RES. 1/4W J 68 OHM 1 1 1 1 1 1 1
R109 CHIP RES.(1608) 1/10W J 75 OHM 1 1 1 1 1 1 1
R110 CARBON RES. 1/4W J 1K OHM 1 1 1 1 1 1 1
R112 CARBON RES. 1/4W J 1K OHM 1 1 1 1 1 1 1
R113 CARBON RES. 1/6W J 4.7K OHM 1 1 1 1 1 1 1
R115 CARBON RES. 1/6W J 4.7K OHM 1 1 1 1 1 1 1
R116 CARBON RES. 1/6W J 15K OHM 1 1 1 1 1 1 1
R117 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1 1 1
R118 CARBON RES. 1/4W J 68 OHM 1 1 1 1 1 1 1
R119 CHIP RES.(1608) 1/10W J 75 OHM 1 1 1 1 1 1 1
R120 CARBON RES. 1/6W J 680 OHM 1 1 1 1 1 1 1
R123 CHIP RES.(1608) 1/10W J 220 OHM 1 1 1 1 1 1 1
R125 CARBON RES. 1/6W J 680 OHM 1 1 1 1 1 1 1
R126 CHIP RES.(1608) 1/10W J 220 OHM 1 1 1 1 1 1 1
R127 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1 1
R128 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1 1
FUNCTION CBA
R652 CHIP RES.(1608) 1/10W J 1.2K OHM 1 1 1 1 1 1 1
R653 CHIP RES.(1608) 1/10W J 1.5K OHM 1 1 1 1 1 1 1
R654 CHIP RES.(1608) 1/10W J 2.2K OHM 1 1 1 1 1 1 1
R655 CHIP RES.(1608) 1/10W J 3.9K OHM 1 1 1 1 1 1 1
SWITCHES
SW651 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW652 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW653 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW654 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW656 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
VPS CBA
CAPACITORS
C640 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1
C642 SEMICONDUCTOR CAP. SR K 0.056UF/25V 1 1 1 1 1 1 1
C643 ELECTROLYTIC CAP. 4.7UF/25V M H7 1 1 1 1 1 1 1
C644 ELECTROLYTIC CAP. 47UF/6.3V M H7 1 1 1 1 1 1 1
C645 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1
C648 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1 1 1 1 1
C649 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1 1 1 1 1
IC’s
IC640 9965 000 12198 IC:VPS/PDC SLICER LC74793JM-TRM 1 1 1 1 1 1 1
RESISTORS
R638 CHIP RES.(1608) 1/10W J 100 OHM 1 1 1 1 1 1 1
R641 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1 1 1
R642 CHIP RES.(1608) 1/10W J 2.7K OHM 1 1 1 1 1 1 1
R643 CHIP RES.(1608) 1/10W J 5.6K OHM 1 1 1 1 1 1 1
R644 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1 1 1
R645 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1 1 1
POWER SW CBA
SW510 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SENSOR CBA
Q504 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1 1 1 1 1 1 1
Q505 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1 1 1 1 1 1 1
FUNCTION CBA
CN651 9965 000 09213 ANGLE PIN HEADER, 3P 6029B-1-03Z002-T 1 1 1 1 1 1 1
RESISTORS
R652 CARBON RES. 1/6W J 1K OHM 1 1 1 1 1 1 1
R653 CARBON RES. 1/6W J 1.2K OHM 1 1 1 1 1 1 1
R654 CARBON RES. 1/6W J 1.5K OHM 1 1 1 1 1 1 1
R655 CARBON RES. 1/6W J 2.2K OHM 1 1 1 1 1 1 1
R668 CARBON RES. 1/6W J 3.9K OHM 1 1 1 1 1 1 1
1-16-23
