ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR732/02 VR732/39 VR730/07 VR730/39 VR732/16 VR730/02 VR730/16
SWITCHES
SW671 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW672 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW673 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW674 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW675 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
AFV CBA
CAPACITORS
C1 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1
C4 CHIP CERAMIC CAP. CH J 56PF/50V 1 1 1 1 1 1 1
C5 CHIP CERAMIC CAP. CH J 22PF/50V 1 1 1 1 1 1 1
C6 CHIP CERAMIC CAP. CH J 56PF/50V 1 1 1 1 1 1 1
C7 CHIP CERAMIC CAP. CH D 3PF/50V 1 1 1 1 1 1 1
C8 CHIP CERAMIC CAP. CH D 3PF/50V 1 1 1 1 1 1 1
C11 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1
C12 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1 1 1 1 1
C13 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1
C14 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1
C15 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1 1 1 1 1
C16 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1 1 1 1 1
C17 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1
C19 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1
C20 ELECTROLYTIC CAP. 3.3UF/50V M H7 1 1 1 1 1 1 1
C21 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1
C22 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1 1 1 1 1
C23 CHIP CERAMIC CAP. F Z 0.47UF/10V 1 1
C24 ELECTROLYTIC CAP. 0.22UF/50V M H7 1 1 1 1 1 1 1
CN1 4822 265 11267 ANGLE PIN HEADER, 9P 6029B-1-09Z003-T 1 1 1 1 1 1 1
DIODES
D2 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
IC’s
IC1 9965 000 12199 IC:AUDIO PROCESSOR MSP3417G-QG-B8 1 1 1 1 1
IC1 9965 000 12274 IC:AUDIO PROCESSOR MSP3407G-QG-B8 1 1
COILS
L1 4822 157 10889 INDUCTOR 10UH-K-26T 1 1 1 1 1 1 1
L2 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1 1 1
L3 4822 157 11318 INDUCTOR 18UH-K-26T 1 1 1 1 1 1 1
L4 4822 157 10889 INDUCTOR 10UH-K-26T 1 1 1 1 1 1 1
RESISTORS
R1 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1 1 1 1 1
R2 CHIP RES.(1608) 1/10W 0 OHM 1 1
R4 CHIP RES.(1608) 1/10W J 120K OHM 1 1 1 1 1 1 1
R5 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1 1
R6 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1 1
R7 CHIP RES.(1608) 1/10W J 1.2K OHM 1 1
X1 9965 000 12200 X’TAL 18.432MHZ 1 1 1 1 1 1 1
