2.3 GW PL HART8+AI-BUS expansion module
The GW PL HART8+AI-BUS expansion module functions similarly to the GW PL HART8-
BUS expansion module, but also supplies the loop current to HART slaves, including loop
resistance, and adds the ability to transmit analog data. Up to five HART expansion
modules can be connected to the head station, allowing a maximum of 40 HART channels
to be operated in parallel. Each channel provides galvanic isolation from the HART signal.
Figure 2-9 GW PL HART8+AI-BUS structure
S6
H+6
S5
H-5
S6
H+6
S6
H-6
S1
H+1
S1
H-1
S2
H+2
S2
H-2
S
8
8
8
8
4
4
44
7
777
3
33
3
55
55
6
6
6
62
2
22
1
1
1
1
H+
H-
S
SH+H-
S
SH+H- S S H+ H- S
S
H+ H- S S H+ H- S
SH+
H- S
S
H+ H- S
GW PL HART8+AI-BUS
CH1
CH2 CH5 CH6
CH8
CH7CH4CH3
6
2
4
8
3
7
5
1
9
10
Table 2-4 GW PL HART8+AI-BUS structure
Item Function
1 Channel 1 connector
2 Channel 2 connector
3 Channel 3 connector
4 Channel 4 connector
5 Channel 5 connector
6 Channel 6 connector
7 Channel 7 connector
8 Channel 8 connector
9 Status LEDs (one per channel)
10 BUS connector
