System description
3433_en_C PHOENIX CONTACT 11/46
2.3.1 Connections
HART
Connect the HART field devices according to Figure 2-10 and Figure 2-11. An optional
isolator or repeater power supply may be installed.
Figure 2-10 HART direct connection with current power
Figure 2-11 Intrinsically safe HART connection
+
-
+
-
GW PL HART8+AI-BUS
H+
H-
+
-
+
-
GW PL HART8+AI-BUS
A
H+
H-
A Optional isolator or
repeater power supply
