Instruction & Maintenance Manual Sheet 1.32
Phoenix ‘SPC10e’ Self Propelled Metering Chipping Spreader 03/12
Engine Air Cleaner Blockage Warning
A vacuum gauge will light a RED light in the front console
should the air cleaner become too restricted (blocked).
It will then require cleaning or a new element to be
fitted. See the section regarding air filter maintenance
in section 2.
Transmission Oil Pressure
This illuminates when a loss of pressure to the transmission
gearbox occurs. In the first instance, put the transmission into
LOW speed range and move the machine to a safe location for
repair.
The low pressure warning light may illuminate if the
pressure filter is blocked or there is a loss of flow
from the supply pump.
Low Air Pressure Warning
This illuminates when the air pressure from the air compressor
is below the minimum required to operate the centre hopper cut-
off-blades. The cut-off-blades will stay in their position and not
move when switched.
