Instruction & Maintenance Manual Sheet 1.29
Phoenix ‘SPC10e’ Self Propelled Metering Chipping Spreader 03/12
Control & Gauge Types and Locations
The following engine and transmission controls are provided for
the operator of the ‘SPC10e’. They are located in either the –
Front steering column and console, immediately to
front
Stack on steering wheel column
Side arm console (part of seat arm rest)
Foot controls in floor under the front console
Right (RH) console adjacent to right armrest
Overhead console above the windscreen
Location
Ignition switch (key switch) front console
Engine throttle control switch - PERKINS front console
Engine throttle control switch - JCB RH console
Parking Brake RH console
Brake foot pedal (service brake) floor
Steering control (wheel) front console
Joystick with additional switches side arm console
Speed control switch (Low/High) front console
Ground Speed Adjuster RH console
Ground Speed ON/OFF switch RH console
Indicator/headlamp dip/horn stalk stalk
Headlamp/sidelamp switch front console
Headlight dip/mainbeam control stalk
Horn warning switch stalk
Hazard beacon switch. front console
Fog light (rear) switch front console
Windscreen wiper switch overhead console
Windscreen washer switch. overhead console
Working lights – Cab roof overhead console
MidRange Speed switch front console
See Fig. SE902-10,
SE902-05B (PERKINS) &
SE902-26D (JCB)
