19
AM844D
Model Name AM 844D
Inputs
Total Channels 12
Balanced Mono Mic / Line channel 8
Balanced Mic / Stereo Line channel 2
Balanced Stereo Line Channel 2
Aux Return 4 stereo
2T Input Stereo RCA
Outputs
Main L/R Stereo 2 x 1/4” TRS, Bal. & 2 x XLR
Main out with inserts Yes
Rec Out Stereo RCA
CTRL RM L/R 2 x 1/4” TS
Phones 2
Direct Out Mic/Line Ch1~ Ch8
Channel Strips 12
Aux Sends 4
Pan/Balance Control Yes
Channel Insert Ch 1 ~ Ch 8
Volume Controls 60mm fader
Master Section
Aux Send Masters 3
Master Aux Send Solo 3
Stereo Aux Returns 4
Aux Return Assign to Subgroup 1
Effects Return to Monitor 2
Global AFL/PFL Solo Mode Yes
Faders 4 subgroups, Main L & R
Metering
Number of Channels 2
Segments 12
Phantom Power Supply +48V DC
Switches Master
32/40-bit Digital Effect Processor 100 effects with tap delay control,
Test tone and foot switch (effect on/off)
Frequency Response
(Mic input to any output)
20Hz ~ 60KHz +0/-1 dB
20Hz ~ 100KHz +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz
bandwidth, channel in to main L/R outputs)
Channel fader down, other channels at unity
<-90 dB
SPECIFICATIONS
