Phonic MAX 860 - Part Lists; Input Connectors Part List

Page12
PHONICCORPORATION
INPUTCONNECTORSPARTLIST
MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
IC1 160-00007-500-0 IC NJM 2068D JRC
JK2A.3A 211-01602-560-0 6D4/J YLJ-6405-300
(NUT&WASHER)
JK2.3 211-03300-160-0 XLR/J SKCA229-1K3F2
JK4.5 211-03400-021-0 SPEAKON/J SVP563S-CH
A2 212-10010-680-0 1P WAFER/P 80MM UL1015#14 BLK
A4 212-10010-690-0 1P WAFER/P 80MM BWN
A1 212-10010-720-0 1P WAFER/P 80MM UL1015#14 RED
A3 212-10010-730-0 1P WAFER/P 80MM UL1015#14
ORANGE
JP1 212-11214-000-0 IC/P 120MM
R101.103.122.124 006-10032-440-0 MF RES. 100K F 0.25W
R104-107.125-128 006-15022-440-0 MF RES. 15K F 0.25W T
R102.123 006-22022-440-0 MF RES 22K F 0.25W T
C131.132 042-10326-050-0 C/C2 0.01MF M 50V 5 T
C101.102.112.113 042-22024-050-0 C/C2 22PF J 50V 5 T
INPUTCONNECTORSPARTLIST
