Phonic MAX 860 - Power Requirement Classification

Page24
PHONICCORPORATION
POWERREQUIREMENTCLASSIFICATION
POWERREQUIREMENTCLASSIFICATION
MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
BS
070-20588-800-0 X'MER 115/230V MAX2500
280-1538B-000-0 FUSE 15A 250V UL/CSA/JIS S
FUSE2.3 280-20263-000-0 FUSE T2A 250V VDE S
370-26640-432-6 P/CORD 250V/15A 2.5M 3P BS
527-11000-000-0 STR.REL BUSHING 6W3-4 R
(6N3-4 )
573-10032-010-0 POWER LABEL (ONLY USED IN BS)
JIS
070-20580-600-0 X'MER 100V JIS MAX2500
280-2026B-000-0 FUSE 2A 250V UL/CSA/JIS S
280-2538B-000-0 FUSE 25A 250V S UL/CSA/JIS
370-24810-602-0 P/CORD 125V/15A 2.0MM/2P 2.5M
JIS
527-11000-000-0 STR.REL BUSHING 6W3-4 R (6N3-4)
SA
070-20588-800-0 X'MER 115/230V MAX2500
280-1538B-000-0 FUSE 15A 250V UL/CSA/JIS S
280-20263-000-0 FUSE T2A 250V VDE S
370-15020-829-0 P/CORD 15A/250V 1.0MM*3 6F 3P
527-11000-000-0 STR.REL BUSHING 6W3-4 R (6N3-4)
IEC
070-20588-800-0 X'MER 115/230V MAX2500
280-1538B-000-0 FUSE 15A 250V UL/CSA/JIS S
280-20263-000-0 FUSE T2A 250V VDE S
370-23610-902-0 P/CORD 230V 15A 2.5M3P
527-11000-000-0 STR.REL BUSHING 6W3-4 R (6N3-4)
