Phonic MAX 860 - Power Amp(R) & Power Supply Part List

Page14
PHONICCORPORATION MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
CN1.2 211-09142-000-0 14P B.E./S 180DEGREE
CN4.5 211-10021-161-0 2P WAFER/S TJC3-2A P=2.5MM
180DEGREE
CN5
212-10023-470-0 2P WAFER/P 150MM
J1-J1 212-10032-000-6 3P WAFER/P L=350MM
313-00000-000-0 TRANSISTOR WASHER TO-220
Q210.228 313-00010-000-0 WASHER TO-3P
H+ H- L+ L P_GND- V+VAC 315-00012-000-0 LUG PIN JP-15
D101.102*1 322-05000-100-0 TUBE 5MM*D1
R240.247.215.218.D211.212.216.217
.221.222.214.215*2.LED405*1
322-31000-100-0 TUBE 10MM*D1
526-20053-010-0 HEAT SINK MAX SERIES PHONIC
552-20065-400-0 IC FIXED MAX2500
THERMAL SW*2 STHERMAL RES.*1
IC*6
590-43010-100-0 M/E PAN SCR. M3.0*10 NI
FIX TRANSISTOR 590-43012-100-0 M/E PAN SCR. M3.0*12 NI
PAD ON FIX TRANSISTOR 590-43014-100-0 M/E PAN SCR M3.0*14 NI
610-00300-501-0 PLA. WAS. D3.0*D7.0*0.5 NI
610-60300-501-0 PAN SPR. WAS D3.0*D7*0.5 NI
615-60026-620-0 LED BOSS LET5-3
R154.155.158.162.213.214.220.221.4
26.438
006-10002-440-0 MF RES. 100 F 0.25W T
R159.163.203.204.212.216.217.219.2
79.441
006-10012-420-0 MF RES. 1K F 0.25W M
R117.138.145.150.157.161.208.211.2
65.267.276.424.431.432.439
006-10022-440-0 MF RES. 10K F 0.25W T
R146.151.427.434 006-10032-440-0 MF RES. 100K F 0.25WT
R207.234.235.236.254.255.256 006-10072-440-0 MF RES 10 F 1/4W
R108.129.430 006-12022-440-0 MF RES 12KF 0.25W T
R120.141 006-15002-420-0 MF RES. 150 F 0.25W M
R274 006-18022-440-0 MF RES. 18K F 0.25W T
R113.114.115.134.135.136 006-22002-410-0 MF RES. 220 F 0.25W P
R147.152.222.224.228.229.423.435 006-22012-440-0 MF RES 2K2 F 0.25W T
R112.133.425.436.437.440 006-22022-440-0 MF RES 22K F 0.25W T
R420.421.422 006-22032-420-0 MF RES. 220K F 0.25W M
R225.226 006-24022-440-0 MF RES. 24K F 0.25W T
