PHONICCORPORATION MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
R275 006-27032-420-0 MF RES. 270K F 0.25W M
R223.227 006-30012-440-0 MF RES. 3K F 0.25W T
R273 006-30022-420-0 MF RES. 30K F 0.25W M
R266 006-33002-440-0 MF RES. 330 F 0.25W T
R116.119.137.140.165.428 006-33012-440-0 MF RES. 3K3 F 0.25W T
R164.268.442 006-33022-440-0 MF RES. 33K F 0.25W T
R121.142.205.206.417.418 006-39012-420-0 MF RES. 3K9 F 0.25W M
R143.148 006-39022-440-6 MF RES 39K F 0.25W T
R110.131 006-43012-400-0 MF RES. 4K3 F 0.25W T
R118.139 006-43022-420-0 MF RES. 43K F 0.25W M
R271 006-47012-420-0 MF RES. 4K7 F 0.25W M
R111.132 006-47022-440-0 MF RES. 47K F 0.25W T
R201 006-49912-440-0 MF RES. 4K99 F 0.25W T
R230.260.264.277.278 006-51072-420-0 MF RES. 51F 0.25W M
R429 006-56022-440-6 MF RES. 56K +/-1% 0.25W T
R270.419 006-68012-440-0 MF RES. 6K8 F 0.25W T
R156.160.209.210.433 006-68022-420-0 MF RES. 68K F 0.25W M
R144.149 006-68032-440-0 MF RES. 680K F 0.25W T
R401 006-75002-420-0 MF RES. 750 F 0.25W M
R202 006-75022-420-0 MF RES. 75K F 0.25W T
R109.130 006-82022-440-0 MF RES. 82K F 0.25W T
C126 030-10484-0A0-0 E/C 0.1MF J 100V 5T
C409 030-10558-0A0-0 E/C 1MF Z 50V 5*11 T
C127 030-10656-0A0-0 E/C 10MF M 50V 5*11 T
C219.226.408 030-10725-0A0-0 E/C 100MF K 16V T
C108.109.119.120 030-22628-0A0-0 E/C 22MF Z 16V 5*11 T
C410.411.412 030-22638-0A0-0 E/C 22MF Z 25V 5*11 T
C406
030-22728-0A0-0 E/C 220MF Z 16V 8*11 T
C111.122.413.414 030-47638-0A0-0 E/C 47MF Z 25V 6.3*11 T
C212.217 030-47695-000-0 E/C 47MF K 160V P
C205 032-10636-0A0-0 NP E/C 10MF M 25V 6.3*11 T
C106.107.117.118 040-10425-160-0 ML/C 0.1UF 50V K X7R P
C222 042-03020-000-0 C/C2 3PF C 50V 5
C123.124..220.221 042-10144-050-0 C/C2 100PF J 100V 5T
C207.209.225 042-10225-050-0 C/C2 0.001MF K 50V 5 T
C125.129.130 042-10326-050-0 C/C2 0.01MF M 50V 5 T
