Phonic MAX 860 - Miscellaneous Classification Items

Page21
PHONICCORPORATION
MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
POWER SW 210-03101-070-0 SSA/SW
211-17000-410-0 BINDING POST BP-47-2P
SPK-L 212-10010-650-0 1P WAFER/P 100MM UL1015#14
RED
E-444 212-10010-750-6 1P WAFER/P 1617#14 AWG 370MM
BLUE
E-444 212-10010-760-6 1P WAFER/P 1617#14 AWG 320MM
RED
VAC 212-10010-770-0 1P WAFER/P 220MM BLK
P_GND 212-10010-780-0 1P WAFER/P 240MM BWN
V+ 212-10010-790-0 1P WAFER/P 260MM RED
L- 212-10010-800-0 1P WAFER/P 280MM ORANGE
L+ 212-10010-810-0 1P WAFER/P 300MM YLW
H- 212-10010-820-0 1P WAFER/P 320MM BLUE
H+ 212-10010-830-0 1P WAFER/P 340MM WHT
SPK_L 212-10010-840-0 1P WAFER/P 320MM RED
SPK_R 212-10010-850-0 1P WAFER/P 160MM ORANGE
SPK_GND_L 212-10010-860-0 1P WAFER/PP 150MM BLK
SPK_GND_R 212-10010-870-0 1P WAFER/P 150MM BWN
307-00000-070-0 CORD CONNECTOR C5
315-00000-000-0 LUG D4 GROUND
321-00000-070-0 CABLE TIE HW-100MM
347-00000-201-0 FAN JF0825S2H-419
510-21000-902-0 PANEL MAX2500
511-20680-101-0 BACK PANEL MAX2500
516-20440-100-0 TOP COV. MAX SERIES PHONIC
517-20600-100-0 BOT COV. MAX SERIES PHONIC
518-20270-100-0 FAN COV. MAX SERIES PHONIC
525-00009-100-0 FEET D26.5*11 BLK
526-10056-110-0 LINK HEAT SINK
528-00000-000-0 FAN NET WHT PWA2200 8"
528-60012-000-0 NET MAX860/1500/2500
540-20390-120-0 R/KNOB D18*18MM BLK
551-20074-200-0 FIXED SECC T=1.5MM BRKT/R MAX
551-60055-200-0 FIXED SECC T=1.5MM BRKT/L MAX
552-20048-420-0 ADHESIVE FIXED FW-5D-3M
560-21070-100-0 CARTON MAX2500 570*540*100
