PHONICCORPORATION
MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
C318 042-56224-050-0 C/C2 0.0056MF J 50V T
ZD306 090-01103-010-0 Z/DIODE 10V K 0.5W FAIRC
ZD307 090-01153-010-0 Z/DIODE 15V K 0.5W UNIZON
ZD502 090-01472-020-0 ZENER DIODE 4.7V J 0.5W T
ZD303.304.305.501 090-01682-000-0 ZEN/DIODE 6.8V J0.5W UNIZO
ZD301.302 090-01752-010-0 ZEN/DIODE 7V5 K 0.5W FAIRCH
D301.302.303.306.503.504 090-02000-020-0 DIODE 1N4148 T26MM MINI
Q506.508.509.510.512.514.515 120-00000-800-0 TRAN. 2SC1815 GR TOSHIBA
Q301 120-00001-400-0 TRAN. 2N5551 MOTOROLA
Q308 120-00009-700-0 TRAN. BC546B PHILIPS(BC550)
Q507.511.513 121-00000-200-0 TRAN. 2SA1015 GR TOSHIBA
Q304.314.332.333 121-00000-300-0 TRAN. 2N5401 MOTOROLA
Q307 121-00007-500-0 TRAN. BC556B PHILIPS (BC560)
