Phonic MAX 860 - Page 19

PHONICCORPORATION
Page4Page19
MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
R525.536.537.540 006-22022-440-0 MF RES 22K F 0.25W T
R520.521.522 006-22032-420-0 MF RES. 220K F 0.25W M
R325.326 006-24022-440-0 MF RES. 24K F 0.25W T
R375 006-27032-420-0 MF RES. 270K F 0.25W M
R323.327 006-30012-440-0 MF RES. 3K F 0.25W T
R373 006-30022-420-0 MF RES. 30K F 0.25W M
R366 006-33002-440-0 MF RES. 330 F 0.25W T
R528 006-33012-440-0 MF RES. 3K3 F 0.25W T
R368.542 006-33022-440-0 MF RES. 33K F 0.25W T
R305.306.517.518 006-39012-420-0 MF RES. 3K9 F 0.25W M
R371 006-47012-420-0 MF RES. 4K7 F 0.25W M
R301 006-49912-440-0 MF RES. 4K99 F 0.25W T
R330.360.364.377.378 006-51072-420-0 MF RES. 51F 0.25W M
R529 006-56022-440-6 MF RES. 56K +/-1% 0.25W T
R370.519 006-68012-440-0k MF RES. 6K8 F 0.25W T
R309.310.533 006-68022-420-0 MF RES. 68K F 0.25W M
R302 006-75022-420-0 MF RES. 75K F 0.25W T
C509 030-10558-0A0-0 E/C 1MF Z 50V 5*11 T
C9.10.301.303.310. 030-10656-0A0-0 E/C 10MF M 50V 5*11 T
C319.326.508 030-10725-0A0-0 E/C 100MF K 16V T
C510.511.512 030-22638-0A0-0 E/C 22MF Z 25V 5*11 T
C506 030-22728-0A0-0 E/C 220MF Z 16V 8*11 T
C312.317 030-47695-000-0 E/C 47MF K 160V P
C305 032-10636-0A0-0 NP E/C 10MF M 25V 6.3*11 T
C322 042-03020-000-0 C/C2 3PF C 50V 5
CE-3021 C320.321042-101
44-050-0
C/C2 100PF J 100V 5T
C307.309.325 042-10225-050-0 C/C2 0.001MF K 50V 5 T
C314.315 042-10345-160-6 C/C2 0.01UF K 100V T
C331.515.516 042-10426-050-0 C/C2 0.1MF M 50V 5 T
C323.324.327.330 042-104A8-000-0 C/C2 0.1MF Z 250V 5
C329 042-201A5-000-0 C/C2 200PF K 250V
C306 042-33024-050-0 C/C2 33PF J 50V 5 T
C328 042-391A4-050-0 C/C2 390PF J 250V 5 T
C507 042-47124-050-0 C/C2 470PF J 50V 5 T
C313.316 042-47164-050-0 C/C2 470PF J 350V 5 T
C302.304 042-47325-050-0 C/C2 0.047MF K 50V 5 T
