MAX860/1500/2500 SERVICEMANUAL
Ref. Phonic Part No. Specification
IC1 160-00005-909-0 IC 7815
IC301 160-00021-900-0 IC NJM5534D JRC
TMP2 210-10090-001-0 TMP/SW US-602SXRFQC VERIAL
CN7 211-10021-161-0 2P WAFER/S TJC3-2A P=2.5MM
180DEGREE
CN9 211-10084-020-0 8P WAFER/S 396108 180 P=3.96MM
CN8 212-10023-470-0 2P WAFER/P 150MM
JP2 212-11214-000-0 IC/P 120MM
FUSE1 281-00000-010-0 FUSE CLIP FH-1208
FUSE2.3 281-00000-020-0 FUSE CLIP FH-1206
CE-2752 313-00000-000-0 TRANSISTOR WASHER TO-220
Q310.328 313-00010-000-0 WASHER TO-3P
H+ H- L+ L- P2-P9 P_GND V+AC V 315-00012-000-0 LUG PIN JP-15
BD3*1 322-05000-100-0 TUBE 5MM*D1
R340.347.502.315.318.D311.312.316
.317.32
322-31000-100-0 TUBE 10MM*D1
1.322.D314.315*2.LED505*1
KBPC5006 526-20046-010-0 HEAT SINK MAR2000
CE-2628 526-20053-010-0 HEAT SINK MAX PHONIC
CE-267 552-20065-400-0 IC FIXED MAX2500
KBPC5006 590-24020-200-0 M/E BID SCR. M4*20 BLK
THERMAL 590-43010-100-0 M/E PAN SCR. M3.0*10 NI
FIX TRANSISTOR 590-43012-100-0 M/E PAN SCR. M3.0*12 NI
PAD ON FIX TRANSISTOR 590-43014-100-0 M/E PAN SCR M3.0*14 NI
IC1.2 590-53008-100-0 M/E SET SCR. M3.0*8 N
CE-2752 610-00300-501-0 PLA. WAS. D3.0*D7.0*0.5 NI
IC1.2 610-60300-501-0 PAN SPR. WAS D3.0*D7*0.5 NI
KBPC5006 610-60401-001-0 PAN SPR. WAS. D4*7.6*1.0 NI
IC1.2 615-60033-630-0 BOSS CU L=24
R313.314.320.321.526.538 006-10002-440-0 MF RES. 100 F 0.25W T
R303.304.312.316.317.319.379.541 006-10012-420-0 MF RES. 1K F 0.25W M
R308.311.365.367.376.524.531.532.5
39
006-10022-440-0 MF RES. 10K F 0.25W T
R527.534 006-10032-440-0 MF RES. 100K F 0.25W T
R307.334.335.336.354.355.356 006-10072-440-0 MF RES 10 F 1/4W
R530 006-12022-440-0 MF RES 12KF 0.25W T
R374 006-18022-440-0 MF RES. 18K F 0.25W T
R322.324.328.329.523.53 006-22012-440-0 MF RES 2K2 F 0.25W T
