13MU1002X
Inputs
Total Channels 6
Balanced Mono Mic / Line Channel 2
Balanced Stereo Line Channel 4
2T Input Mini stereo and stereo RCA
Outputs
Main L/R Stereo 2x 1/4” TRS, Bal.
EFX Send 1x 1/4” TS
Rec Out Mini stereo and stereo RCA
CTRL RM L/R 2 x 1/4” TS
Phones 1
Channel Strips 6
Efx Send 1
Pan/Balance Control Yes
Volume Controls Rotary
Master Section
Stereo EFX Send Cue 1
EFX Return to Main 1
2T RTN to CTRL RM 1
Phones Level Control Yes
Main L/R Level Control 60 mm fader
Effect Processor (32-bit DSP processing) 16 effects with one main parameter control, tap
delay control, foot switch jacks (effect on/off, tap)
Metering
Number of Channels 2
Segments 5
Phantom Power Supply +48V DC
Switches Master
Frequency Response (Mic input to any output)
20Hz ~ 60KHz +0/-1 dB
20Hz ~ 100KHz +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth,
channel in to main L/R outputs)
Channel fader down, other channels at unity <-90 dB
SPECIFICATIONS
