Assembly of the U Push Frame
1. Attach the Connect Tube(17) to the front base tube(1), secured with brass color bushing (51-6pcs),
bolt(55-1pcs),washer (65-2pcs) and nylon nut (67-2pcs).
2. Fix the U push frame(left)(19)&(right) (31) to the Connect Tube(17), secured with parts hex bolt
(56-4pcs), washer (64-8pcs) and nylon nut (66-4pcs).
3. Insert the handle bar(11) to the U push frame(left)(19)&(right) (31),locked with quick pin (43).
ASSEMBLY INSTRUCTIONS
