Assembly of the pulley
1. Let pulley (41-14pcs) be assembled on welded pulley brackets(18-2pcs), Reverse pulley
bracket (23), and fl oating pulley bracket (22), secured with all hex bolt (59-11pcs), hex
bolt (56-3pcs), hex bolt (60-2pcs),pulley bush (42-6pcs),washer (64-32pcs) and nylon nut
(66-16pcs).
2. And let all pulleys can turn.
ASSEMBLY INSTRUCTIONS
