Checking the brake fluid level (12_01)
The rear brake fluid tank is located into the driver compartment, near the brake pedal.
Check the level as follows:
1. Stop the vehicle on level ground;
2. Check the oil level is between 1 cm under the surface of cap «A» (MAX level)
and 1 cm over the bottom of the reservoir (MIN level).
12_01
If the oil is under the minimum level contact a PIAGGIO Dealer or Authorised Service
Centre to have the brake system checked.
Topping up brake fluid
To fill the reservoir, unscrew cap «A» and top up.
Under normal climatic conditions, the replacement of the liquid must be carried out as
described in the scheduled maintenance table.
Qualified and skilled personnel are required for this operation. We recommend you
go to a Dealer or Authorised PIAGGIO Service Centre.
CAUTION
ONLY USE DOT 4 CLASSIFIED BRAKE FLUIDS.
WARNING
BRAKING SYSTEM LIQUID IS HAZARDOUS: WASH WITH WATER IN THE
EVENT OF ACCIDENTAL CONTACT.
70
