PIAGGIO APE 50 E4 - Brake Pedal; Headlights Adjustment

12_25
Brake pedal (12_25)
Air bleeding from the braking system
In case of anomalies of the brake performance, accompanied by idle pumping, have
the system drained by the Concessionaires or Authorised PIAGGIO Service Cen-
tres.
IN FACT, THE BRAKE FLUID IS HIGHLY CORROSIVE AND IT MUST BE DIS-
POSED ACCORDING TO PRECISE REGULATIONS. MOREOVER, ANY INTER-
VENTION TO THE BRAKING SYSTEM MUST BE CARRIED OUT ONLY BY
QUALIFIED PERSONNEL.
12_26
12_27
Headlights adjustment (12_26, 12_27)
Proceed as follows:
1. Place the vehicle in conditions of use, without load, with the tyres inflated to
the prescribed pressure on flat grounds at 10 m from a white screen placed
in semidarkness. Make sure the vehicle axis is perpendicular to the screen;
2. Draw two vertical lines "a-a" at a distance «A» corresponding to the distance
between headlight axes. Draw a horizontal line "b-b" at height «B» from
ground corresponding to the headlight centre height from ground multiplied
by 0.9;
3. Start the engine and lock the throttle twist grip at approximately 1/3 of its
travel. Switch the dipped beam headlight on. Direct the beam so that the
horizontal line between the light and the shade falls above the horizontal "b-
b" drawn on the screen;
4. if this is not so, adjust the headlight by means of the two screws «A» to correct
any beam alterations.
86
10 Maintenance
