Fuse No. 2 Capacity: 15 A
Power supply input: switched
live.
Protected circuits: windscreen
wiper motor.
Fuse No. 3 Capacity: 10 A
Power supply input: battery
protected by fuse No. 1.
Protected circuits: internal
lighting, cigarette lighter.
Fuse No. 4 Capacity: 7.5 A
Power supply input: switched
live.
Protected circuits: horn,
windscreen wiper control switch,
turn indicators flasher relay, stop
button on rear brake, oil level
sensor, instrument panel, fuse No.
2, mixer oil warning light flasher
relay.
Fuse No. 5 Capacity: 4 A
Power supply input: switched
live.
Protected circuits: ignition switch
(PARKING function, if available),
cigarette lighter, full headlamp,
front turn indicators.
Fuse No. 6 Capacity: 4 A
84
