SIZES
N. millimetres (mm) TOP CROSS LONG Deck SHORT deck VAN
1 Length 2660 2540 2660 2500 2500
2 Width 1,260 1,260 1,260 1,260 1,260
3 Height 1550 1620 1550 1550 1590
4 Wheelbase 1590 1590 1590 1590 1590
5 Deck length (INTERNAL) 1,350 1,190 1,350 1,190 1,190
5 Deck length (EXTERNAL) 1410 1250 1410 1250 1250
6 Deck width (INTERNAL) 1,200 1,140 1,140 1,140 1,140
6 Deck width (EXTERNAL) 1,260 1,200 1,200 1,200 1,200
7 Width including mirrors 1,460 1,460 1,460 1,460 1,460
- Board height 230 230 230 230 -
WEIGHTS
Kilograms (kg) TOP CROSS LONG Deck SHORT deck VAN
Technically permissible maximum total weight 500 500 500 500 490
Kerb vehicle mass 255 255 255 240 268
Kerb vehicle mass with driver 330 330 330 315 345
Maximum weight permissible on the front axle 150 150 150 150 150
Maximum weight permissible on rear axle 410 410 410 410 410
Useful load capacity ±3% 170 170 170 185 145
97
11 Technical data
