CAUTION
MODIFICATIONS OR REPAIRS TO THE ELECTRICAL SYSTEM, PERFORMED
INCORRECTLY OR WITHOUT STRICT ATTENTION TO THE TECHNICAL SPEC-
IFICATIONS OF THE SYSTEM, CAN CAUSE ERRORS IN FUNCTIONING AND
RISK OF FIRE.
FUSES
General Position on fuse box: 1
Fuse: 30A
Protected circuits: General
Electronic control unit remote
control switch
Position on fuse box: 2
Fuse: 10A
Protected circuits: Electronic
control unit remote control switch
Basic power supply to control unit,
immobilizer
Position on fuse box: 3
Fuse: 5A
Protected circuits: Basic power
supply to control unit, immobilizer
Control unit live Position on fuse box: 4
Fuse: 5A
