Protected circuits: Control unit
live
Outlet 12V-180W, button for
helmet compartment lighting, bulb
for helmet compartment lighting,
contacts for key switch, actuator for
seat opening, electrical button
opening
Position on fuse box: 5
Fuse: 15A
Protected circuits: Outlet
12V-180W, button for helmet
compartment lighting, bulb for
helmet compartment lighting,
contacts for key switch, actuator for
saddle opening, electrical button
opening
Light remote control Position on fuse box: 6
Fuse: 10A
Protected circuits: Light remote
control
Light flash, fitting for accessories,
horn
Position on fuse box: 7
Fuse: 15A
Protected circuits: Light flash,
fitting for accessories, horn
Stop lights, preparation for radio
and anti-theft device, damper,
instrument panel live
Position on fuse box: 8
Fuse: 7.5A
Protected circuits: Stop lights,
preparation for radio and anti-theft
device, damper, instrument panel
live
53
