01_22
01_23
Accessing the fuel tank (01_22, 01_23)
To open the fuel tank cover, set the key to «OFF» or « ON», then press and turn it
clockwise.
01_24
The saddle (01_24, 01_25, 01_26)
The saddle is supplied with a protection cover which may be used in case of rain.
Lift the saddle and extract the cover from its housing, then extend it over the whole
length of the saddle, starting from the front-end; do not over stretch the cover to avoid
tearing the material; close the saddle.
26
