TYRES
Front tyre Tubeless, 120/70-12" 51S or 51P
Rear tyre Tubeless 120/70-14" 68S or 68P
TYRE INFLATION PRESSURE
Front tyre pressure 1.6 bar
Rear tyre pressure 2.5 bar
03_09
Spark plug dismantlement (03_09, 03_10)
Remove the port on the left-hand side panel of the vehicle by undoing the fixing screw
«A» and using a small screwdriver in the rear notch shown in the figure, then proceed
as follows:
1. Disconnect spark plug HV wire cap «B»;
2. Unscrew the spark plug using the wrench supplied.;
3. When refitting, place the spark plug in the hole at the due inclination and tighten it
by hand until it is finger tight;
4. Only use the wrench to lock it in place;
5. Place cap «B» fully over the spark plug.
6. Refit the port making sure the rear hook is inserted.
62
