03_17
03_18
A drop in the brake fuel level may be caused by pad wear. Should the level appear to
be below the minimum mark, please contact an Authorised Service Centre or Deal-
er in order to have the braking system thoroughly checked.
03_19
Braking system fluid top up (03_19, 03_20, 03_21)
Proceed as follows:
Loosen the screw «B» and lift the plastic cover «A» in order to access the brake fluid
reservoir. Loosen the two fastener screws and remove the reservoir cap and top up
with the recommended fluid only.
This procedure applies to the rear brake pump top-up operation; follow the same pro-
cedure for the front brake pump.
To top up the integral braking system brake fluid, partially remove the fluid reservoir
from its mounting, taking care not to detach the pipe. Loosen screw "F", lift out the
reservoir as shown in the photo and remove the cap to top up the fluid level.
67
