Front brake Ø 240 mm double disc brake with
hydraulic control activated by the
handlebar right-hand lever.
Rear brake Ø 240 mm disc brake, with
hydraulic control activated by the
handlebar left-hand lever.
Integral braking system The system operates all three
discs simultaneously and is
controlled hydraulically via the
pedal on the footrest.
Wheel rim type Light alloy rims.
Front rim 12'' x 3.00
Rear rim 14'' x 4.50
Front tyre Tubeless, 120/70-12" 51S or 51P
Rear tyre Tubeless 120/70-14" 68S or 68P
Front tyre pressure 1.6 bar
Rear tyre pressure 2.5 bar
Kerb weight 253 ± 8 kg
Maximum weight allowed 445 kg
Battery 12V/14 Ah, sealed battery
CAPACITY
Engine oil 1.7 l
Transmission oil 250 cm³
95
