Transmission
TRANSMISSIONS
Specification Desc./Quantity
Transmission With automatic expandable pulley variator with torque server,
V belt, automatic clutch, gear reduction unit and transmission
housing with forced air circulation cooling.
Capacities
CAPACITIES
Specification Desc./Quantity
Cooling system approx. 1.8 l
Fuel tank (including reserve ~ 2.5 l) ~ 14,5 l
Rear hub ~ 250 cc
Engine oil (empty) 1.7 lt.
Engine oil (at oil and filter change) 1.5 lt.
Electrical system
ELECTRICAL COMPONENTS
Specification
Desc./Quantity
1 Ignition type Inductive, high efficiency, integrated with injection, vari-
able advance and separate HV coil.
2 Spark advance (before TDC) Variable, controlled by the injection controller
3 Spark plug CHAMPION RG6YC; NGK CR7EKB
4 Battery 12V-14Ah
5 Fuses n.1 70A_n.1 30A_n.2 15A_n.3 10A_n.4 7,5A_n.2 5A_n.
1 3A
6 Generator in three-phase alternating current
Frame and suspensions
FRAME AND SUSPENSIONS
Specification
Desc./Quantity
Type Welded structure consisting of steel pipes with asymmetrical
trestle structure, front crosspieces and union members made
of sheet steel.
Front suspension Hydraulic telescopic fork with dual effect, Ø 40 mm stems and
back pin with couplongs for dual brake calipers.
Front fork stroke 104 mm
Rear suspension Engine based on oscillating fork pivoted to the chassis by 2-
freedom degree oscillating arm and pair of dual effect hydraulic
shock absorbers with 4-position preload adjustment
Rear suspension range 76.6 mm (minimum spring preload)
X9 Evolution 125-250-500:
Please take note that, starting from chassis serial number ZAPM2300003509521, the front small chas-
sis fixing system has changed in order to improve its locking to the chassis. Therefore we have
introduced:
• N°2 screws drawing 432142
• N°2 4x11x0 external teeth spring washers drawing 012533
• N°2 nuts drawing 968224
Characteristics X9 Evolution 500
CHAR - 10
