<40 A

YES go to 10 NO go to 11

7- Low trailing speed

High electrical absorption

Carry out a test of the engine rotation (example: possible melting of the bushes) and if no anomalies

are found, replace the starter motor.

8- Low trailing speed

Low electrical absorption

Repeat the test, bridging the power terminals of the starter remote control switch or even better replacing

them.

Check the new values.

YES go to 12 NO go to 13

9 - High trailing speed

Low electrical absorption

The engine turns too freely, check the compression end pressure.

If the values are not correct proceed as follows.

10 - The starter motor works properly.

11 - Check the rotation of the armature.

12 - Replace the starter remote control switch.

13 - Test the battery again and if necessary replace the starter motor.

N.B.

IF THE TRAILING SPEED OF THE CRANKSHAFT IS LOW AND COMBINED WITH STRANGE

NOISE, CHECK THE FREEWHEEL OF THE TORQUE LIMITER (SEE THE "FLYWHEEL AND

STARTER SYSTEM" CHAPTER).

STARTER MOTOR

Specification

Desc./Quantity

Type Mitsuba sm13d

Power 0.9 kW

BATTERY

Specification

Desc./Quantity

Capacity 14 Ah

Starting current 125 A

START-UP REMOTE CONTROL SWITCH

Specification

Desc./Quantity

Type SEALED

Maximum load 150 A continuous

STARTER TRANSMISSION

Specification

Desc./Quantity

Ring gear and freewheel coaxial to the flywheel. Intermediate gear with built-in torque limiter.

The starter system has a transmission between the motor armature and engine shaft equipped with

freewheel coaxial to the flywheel and torque limiter on the intermediate shaft.

Engine X9 Evolution 500

ENG - 128
