- Insert the intermediate gear with torque limiter
- Lubricate the inside bushing and the starter ring
gear hub surface.
- Install the start-up rim on the flywheel turning it
clockwise and inserting at the same time.
Refitting the flywheel magneto
- Insert the key on the crankshaft.
- Install the flywheel checking the proper insertion
of the key and engaging the torque limiter gear
with the start-up rim.
