Specification Desc./Quantity
29 Front left-hand direction indicator with bulb
30 Analogue instrument unit (5 bulbs)
31 Radio display
32 Digital instrument unit with no. 11 LED indicators
33 Front headlight
34 Front right-hand direction indicator with bulb
35 Diode unit
36 Diode 6A
37 Diode 1A
38 Main remote control switch 30A
39 Socket 12V
40 Helmet compartment glass bowl with lamp
41 Rear brake light with no. 5 bulbs
42 Number plate light with bulb
43 RH taillight with sidelights bulb and flashing light bulb
44 Start-up remote control switch
45 Battery 12V-14Ah
46 Helmet compartment light button
47 Starter motor
48 No. 3 7.5A fuses
49 Fuse holder box
50 Fuse 15A
51 HV coil
52 Connector cap
53 Saddle opening button
54 Fuel level indicator with pump
55 Immobilizer aerial
56 Key switch
57 Anti-theft alarm fitting
58 Electric fan
59 Electric fan remote control switch 30A
60 Fitting for accessories
61 Side stand button
62 Start up button
63 Reset button
64 Actuators control unit
65 Engine stop switch
66 Decoder
67 Front brake stop button
68 Wheel rpm sensor
69 Injection ECU
70 Side stand pump motor
71 End of stroke button
72 Enable button
73 No. 2 buttons with clamp
74 Fuel injector
75 Throttle potentiometer
76 Idle adjustment motor
77 Engine rpm sensor
78 Engine rpm sensor
79 Engine water temperature sensor
80 Stuck relay indicator
81 Engine oil pressure sensor
82 Magneto flywheel
WIRING COLOUR CHART:
B = White - Bl = Blue - G = Yellow - Mr = Brown - N = Black - BV = White - Green - GN = Yellow - Black
- G = Grey - Rs Pink - R = Red - Vi = Purple - V = Green - VN = Green - Black - BN = White - Black -
BBl = White - Blue - GV = Yellow - Green - Ar = Orange - Az = Light blue - GrBl = Grey - Blue - GrN
= Grey - Black.
CAUTION
X9 Evolution 500 Electrical system
ELE SYS - 55
