Programming
- Remove the front shield to access the saddle
opening reception/control unit.
- In the wiring cover you can see the metal terminal
of the white wire protruding from Pin 3 of the con-
trol unit.
- To program, the remote controls, set the key switch to «ON» for 1 to 3 seconds, then set it to «OFF».
- Within 10 seconds, reset the switch to «ON» and within 3 seconds, press the remote control button,
then set to «OFF» again.
- If the saddle opens with this last operation, the programming was successful.
- You can program up to 7 remote controls by the above procedure.
X9 Evolution 500 Electrical system
ELE SYS - 83
