Echolution 2 | Echolution 2 Deluxe
Echolution 2 | Echolution 2 Deluxe
ADJUSTABLE FILTER CUTOFF FREQUENCY:Sendthedesired
value(0-127)toMIDICC#74tochangethecornerfrequencyofthecurrentlyenabledlter
SECOND TAP VOLUME:Sendthedesiredvalue(0-127)toMIDICC#76to
changethevolumeofthesecondtap.
SETTING JUMP INVTERVALS:MIDICC#77&78Sendinga1willdecrement
thepitch,sendinga2willincrementthepitch.
Tosettheintervalsoftherstandsecondtapsexplicitly,followthistable(sendtoCC#77
forFirstTapandCC#78forSecondTap:
MIDI CC MAP
UP
16-MINOR2nd
17-MAJOR2nd
18-MINOR3rd
19-MAJOR3rd
20-PERFECT4th
21-TRITONE
22-PERFECT5th
23-MINOR6th
24-MAJOR6th
25-MINOR7th
26-MAJOR7th
27-Octave
DOWN
3-Octave
4-MAJOR7th
5-MINOR7th
6-MAJOR6th
7-MINOR6th
8-PERFECT5th
9-TRITONE
10-PERFECT4th
11-MAJOR3rd
12-MINOR3rd
13-MAJOR2nd
14-MINOR2nd
MIDI CC MAP
LOOPING :Sendamomentary1toCC#31toStartaLoop,thensendanother
to Close that Loop.
ThePresetSaveCommandcanbeusedtosaveapreset,afterusingothermidicommands
tochangeparameters.
Buttonscanbecontrolledintwoways,toallowautomatedpatchesandalsorealtime
manualcontrol.
BUTTON PATCH CONTROL
Setthebuttonvalueto“1”foraSHORT PRESS.
Setthebuttonvalueto“2”foraLONG PRESS
ThisallowscommandstobesentquicklytotheE2withoutworryingabouttiming,which
makesautomatedcontroleasy.
MANUAL BUTTON CONTROL VIA MIDI
ThisisconvenientformanualcontroloftheE2throughsomethinglikeafootcontroller,
butwouldbeveryinconvenientforautomatedcontrol.Setthebuttonto“127”toindicate
thatthebuttonshouldchangestatefrom“unpressed”to“pressed”.Setthebuttonto
“0”toindicatethatthebuttonshouldchangestatefrom“pressed”to“unpressed”.The
timebetweentheabovetwomessagesdecidesifthepressisalongorshortpress.This
meansthatthecontrollingbuttonontheMIDIcontrollerbehavesexactlyastheequivalent
buttonwouldontheE2frontpanel.ManualandPatchcontrolscanbemixedasnecessary.
CLASSIC
15-Non-latchingJump
