PIKO SmartControl light User Manual

light
15
Page 2 of the conguration menu includes the following points:
1 = loco-warnings
2 = 32.000 functions
3 = routes
4 = turnout conguration
5.2.1. Menu point “language“
By pressing [1] on page 1 of the conguration menu you can retrieve the language settings. The
desired language can be selected with the [▲] and [▼] keys and has to be conrmed by pressing on
[↩].
You can choose between the following languages:
• German (default setting)
• Danish
• English
• French
• Italian
• Dutch
• Polish
• Swedish
• Spanish
5.2.2. Menu point „brightness“
By pressing [2] on page 1 of the conguration menu you can set the brightness of the display. You can
choose between 15 brightness levels. The brightness can be selected with the [▲] and [▼] keys. The
brightness of the value number on the display shows the actual brightness level that will be set. The
level has to be conrmed by pressing on the [↩] key.
5.2.3. Menu point “help“
By pressing on [3] on page 1 of the conguration menu you can reach the help function. When
switched on, small helping windows will appear for every step in the “congurations” and “change
loco data” modes. You can turn the help function on and off with the [▲] and [▼] key. To conrm your
selection press [↩].
5.2.4. Menu point “throttle“
With the PIKO SmartController
light
you can switch between a DC and an AC driving mode (s. point 4.2
and 4.3). The device is factory-set in DC driving mode.
By pressing [4] on page 1 of the conguration menu you get to the menu point “throttle”. With the
[▲] - and [▼] -keys you can switch between the two modes. To conrm your selection press [↩]. For
more information, please see chapter 5.6 “loco mode”.
