PIKO SmartControl light User Manual

light
25
Red LED off - Green LED on Track current switched on
(normal operating status)
Red LED on - Green LED off Track current switched off
(stop key pressed, short circuit or during active
decoder programming)
RedLEDon-GreenLEDashing Overtemperature
RedLEDashing-GreenLEDoff Undervoltage at the LocoNet
®
T power supply
(Overload on the LocoNet
®
T port)
RedLEDoff-GreenLEDashing Digital central currently in LocoNet
®
programming mode
III. Technical data
a. Digital central station
• Power supply: Input: 240 V 50 Hz, Output: 15 V= / 2 A
• max. load main track output: 2 A
• max. load programming track output: 250 mA
• max. load LocoNet
®
-T: 500 mA
• Dimensions: 104 x 58 x 33 mm
b. PIKO SmartController
light
• 38 x 20 mm high denition display for a detailed representation of text and symbols
• LocoNet
®
port
• Power consumption during normal LocoNet
®
operation: 25 mA
• Dimensions: 180 x 80 x 35 mm
IV. Safety warnings
