9
Speed regulator
The hand controller is equipped with a rotary encoder wheel to control the speed, the driving direction,
the emergency stop of the locomotive and to choose the locomotive’s data set as well as the symbols
and their position in the name of the locomotive.
The following part describes the different keys of the controller:
up/down([▲]/[▼])
• In loco mode, changing of the special function blocks
light, F1 - F8; light, F9 - F16; light, F17 - F24; light - F32.767 (activate in con-guration
mode)
• In turnouts mode, changing of the base address +8 or -8
• In routes mode, changing of the base address +8 or -8
• In congurationmode, changing of parameters
mode
• Selection of the operating mode: [1] = loco mode, [2] = turnouts mode,
[3] = routes mode, [4] = programming mode, [5] = change loco data,
[6] = conguration mode
lok
• Initiate loco selection or switch back to loco mode from every other mode
keypad
• Number keys [0] - [9], enter loco address, switch into different modes, selection of the
operating mode and sub-menus
stop / delete
•Turn DC voltage on and off, delete last entered number or loco data set
Enter [↩]
• Conrm an input
• Conrm a loco data set in mode “change loco data”
• Initiate input of an address and conrm in loco mode, turnouts mode and routes mode
• Start a reading or programming process in programming mode
