IM_208.CCF.20170508-EN
22
Set up and operating
12.
Incline the device by approx. 45° to the left or
to the right. The yaw axis must keep its position now
(Figure 10). If the axis turns, you must proceed
balancing the axis.
13. Loosen the locking screw of the yaw axis and move
the L-arm forwards or backwards. Find the position
where the yaw axis independently keeps its position
inspite of holding the Gimbal tilted as shown in
figure 10.
14. Tighten the locking screw again.
9
10
After all,
check the tight fixation of all screws well so that the
adjusted balance remains unchanged. Only if the camera is already well
balanced you will have an optimal stabilization result with reduce load on
to the motors. Furthermore, the battery life will be increased.
