Operating Manual PNOZ e1p
21242-EN-13
| 22
Inputs 774130 784130
Max. overall cable resistance Rl-
max
Start circuit and feedback loop 1.000 Ohm 1.000 Ohm
Input circuit, single-channel 1.000 Ohm 1.000 Ohm
Input circuit, dual-channel 2.000 Ohm 2.000 Ohm
Max. line capacitance 450 nF 450 nF
Semiconductor outputs 774130 784130
Overall performance ext. loading,
semiconductor 130 W 130 W
Number of safety outputs
Instantaneous 2 2
Number of auxiliary outputs 1 1
Number of test pulse outputs 2 2
Residual current at "0" signal 4 mA 4 mA
Max. internal voltage drop 1 V 1 V
Switching capability, 2 safety out-
puts under load
Current at UB ≤ 26.5 V 2 A 2 A
Current at UB > 26,5 V 1,5 A 1,5 A
Power at UB ≤ 26.5 V 50 W 50 W
Power at UB > 26,5 V 45 W 45 W
Switching capability, 1 safety out-
put under load
Current at UB ≤ 26.5 V 2,7 A 2,7 A
Current at UB > 26,5 V 2,2 A 2,2 A
Power at UB ≤ 26.5 V 70 W 70 W
Power at UB > 26,5 V 65 W 65 W
Conditional rated short circuit cur-
rent 100 A 100 A
Lowest operating current 3 mA 3 mA
Utilisation category in accordance
with EN 60947-1 DC-12 DC-12
Max. line capacitance at the out-
puts without load 2 nF 2 nF
Voltage auxiliary and test pulse
outputs 24 V 24 V
Current auxiliary and test pulse
outputs 0,5 A 0,5 A
Times 774130 784130
Switch-on delay
After power on 3 s 3 s
With automatic start typ. 100 ms 100 ms
With automatic start max. 180 ms 180 ms
With monitored start typ. 180 ms 180 ms
With monitored start max. 260 ms 260 ms
