PNOZ e1p
Operating Manual PNOZ e1p
21242-EN-13
| 26
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product
Product type Features Connection type Order no.
PNOZ e1p 24 V DC Screw terminals 774130
PNOZ e1p C 24 V DC Spring-loaded terminals 784130
Accessories
Product type Features Order no.
Terminal block filter 1 Terminal block with filter for 3-10 kOhm load range 774195
Terminal block filter 2 Terminal block with filter for 10-30 kOhm load range 774196
