Inputs 774131 784131
Current at
Input circuit DC 5 mA 5 mA
Start circuit DC 5 mA 5 mA
Feedback loop DC 5 mA 5 mA
Logic input 5 mA 5 mA
Min. input resistance at power-on 3.780 Ohm 3.780 Ohm
Max. overall cable resistance Rl-
max
Start circuit and feedback loop 1.000 Ohm 1.000 Ohm
Input circuit, single-channel 1.000 Ohm 1.000 Ohm
Input circuit, dual-channel 2.000 Ohm 2.000 Ohm
Max. line capacitance 450 nF 450 nF
Semiconductor outputs 774131 784131
Overall performance ext. loading,
semiconductor 130 W 130 W
Number of safety outputs
Delayed 1 1
Instantaneous 1 1
Number of auxiliary outputs 1 1
Number of test pulse outputs 2 2
Switching capability, 2 safety out-
puts under load
Current at UB ≤ 26.5 V 2 A 2 A
Current at UB > 26,5 V 1,5 A 1,5 A
Power at UB ≤ 26.5 V 50 W 50 W
Power at UB > 26,5 V 45 W 45 W
Switching capability, 1 safety out-
put under load
Current at UB ≤ 26.5 V 2,7 A 2,7 A
Current at UB > 26,5 V 2,2 A 2,2 A
Power at UB ≤ 26.5 V 70 W 70 W
Power at UB > 26,5 V 65 W 65 W
Max. line capacitance at the out-
puts without load 2 nF 2 nF
Voltage auxiliary and test pulse
outputs 24 V 24 V
Current auxiliary and test pulse
outputs 0,5 A 0,5 A
