Function Description
Operating Manual PNOZ m EF Multi Link
1003018-EN-06
| 12
Base unit 1
Virtual outputs
o0
...
o31
Virtual inputs
i0
...
i31
Base unit 2
Virtual inputs
i0
...
i31
Virtual outputs
o0
...
o31
4.3 System reaction time
Calculation of the maximum reaction time between an input switching off and a linked out-
put in the system switching off is described in the document "System Expansion".
4.4 Block diagram
Interface
to previous
module
Interface
to next
module
=
Power
24V 0V n.c.FE
=
CB- CGroundCA- CB+CA+
