Technical details
Operating Manual PNOZ m EF Multi Link
1003018-EN-06
| 19
8 Technical details
General
Certifications CE, EAC (Eurasian), KOSHA, TÜV, cULus Listed
Application range Failsafe
Electrical data
Supply voltage
for Module supply
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+20 %
Output of external power supply (DC) 2,5 W
Potential isolation yes
Supply voltage
for Module supply
internal Via base unit
Voltage 3,3 V
Kind DC
Current consumption 60 mA
Power consumption 0,2 W
Max. power dissipation of module 3 W
Status indicator LED
Fieldbus interface
Galvanic isolation yes
Times
Max. data transmission time 5 ms
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range 0 - 60 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-30, EN 60068-2-78
Condensation during operation Not permitted
Max. operating height above sea level 2000 m
EMC EN 61131-2
Vibration
In accordance with the standard EN 60068-2-6
Frequency 5 - 55 Hz
Acceleration 1g

Pilz PNOZ m EF Multi Link Specifications

General

Brand	Pilz
Model	PNOZ m EF Multi Link
Category	Controller
Language	English
