Technical details
Operating Manual PNOZ m EF Multi Link
1003018-EN-06
| 20
Environmental data
Shock stress
In accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
Airgap creepage
In accordance with the standard EN 61131-2
Overvoltage category II
Pollution degree 2
Protection type
In accordance with the standard EN 60529
Housing IP20
Terminals IP20
Mounting area (e.g. control cabinet) IP54
Potential isolation
Potential isolation between Module and supply voltage
Type of potential isolation Functional insulation
Rated insulation voltage 30 V
Rated surge voltage 2500 V
Potential isolation between Module and system voltage
Type of potential isolation Functional insulation
Rated insulation voltage 30 V
Rated surge voltage 2500 V
Mechanical data
Mounting position horizontally on mounting rail
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Material
Bottom PC
Front PC
Top PC
Connection type Spring-loaded terminal, screw terminal
Mounting type plug-in
Conductor cross section with screw terminals
1 core flexible 0,25 - 2,5 mm², 24 - 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors 0,2 - 1,5 mm², 24 - 16 AWG
Torque setting with screw terminals 0,5 Nm
Conductor cross section with spring-loaded terminals:
Flexible with/without crimp connector 0,2 - 2,5 mm², 24 - 12 AWG
Spring-loaded terminals: Terminal points per connec-
tion 2
Stripping length with spring-loaded terminals 9 mm
