Commissioning
Operating Manual PNOZ m EF Multi Link
1003018-EN-06
| 15
6 Commissioning
6.1 Wiring
The wiring is defined in the circuit diagram of the PNOZmulti Configurator.
Please note:
} Information given in the Technical details [ 19] must be followed.
} The position of the expansion module is specified in the Hardware configuration of the
PNOZmulti Configurator.
} Use copper wiring with a temperature stability of 75 °C.
} The power supply must meet the regulations for extra low voltages with safe separation
(SELV, PELV).
} 2 connection terminals are available for each of the supply connections 24 V and 0 V.
This means that the supply voltage can be looped through several connections. The cur-
rent at each terminal may not exceed 3A.
} The max. cable length between two link modules on a connection with one link module
– PNOZ ml1p <V2.0: 100 m
– PNOZ ml1p from V2.0, PNOZ mml1p, PNOZ m EF Multi Link: 1000 m
} Connect the inputs and outputs from two link modules with a 4-core shielded cable. The
cables must be twisted in pairs.
} Note the crossover cabling, e.g. CA+ with CB+.
} The cables must be classified into a minimum of Category 5 in accordance with ISO/IEC
11801.
CAUTION!
Only connect and disconnect the expansion module when the supply
voltage is switched off.
